H923-BK

Console Insert for Shure MXWNCS4

Attach Shure MXWNCS4 to the base and secure the console insert and equipment in the lectern.
H923 lectern console insert with two handheld microphones and two bodypack transmitters seated in a Shure charger.

This guide is also available as a printable PDF.

In the box

  • Console insert trim for Shure MXWNCS4
  • Base for Shure MXWNCS4
  • Self-adhesive hook-and-loop strip
  • Assembly hardware
Exploded view of the four-opening console trim and separate charger base, with assembly hardware and a roll of self-adhesive hook-and-loop material.

Items needed

  • Shure MXWNCS4 charging station
  • Compatible Shure Microflex Wireless microphones and transmitters

Mount the Shure MXWNCS4 to the base

Position the MXWNCS4 and base beneath the lectern opening

Underside animation showing the rear lip of a console insert sliding beneath the lectern opening while its two retaining knobs remain parallel to the insert edge.

Rotate the retaining knobs to lock the console insert trim

Underside animation showing both retaining knobs rotating outward to secure the console insert beneath the lectern surface.

Insert the Shure microphones and transmitters

Secure the base with the hook-and-loop strip
